EXCELLENT SMALL HIGH GAIN AMPLIFIERS
		HIGH GAIN AMPLIFIER FOR 2.4 GHz RECEIVERS HIGH GAIN AMPLIFIER FOR 900 MHz RECEIVERS HIGH GAIN AMPLIFIER FOR 900 MHz RECEIVERS HIGH GAIN AMPLIFIER FOR TV UHF RECEIVERS HIGH GAIN AMPLIFIER FOR 5.8 GHz RECEIVERS

Model: AMP-18M/24

This is an excellent small amplifier for any receiver (not for transmitters). It will increase a gain of your receiver without adding large 2.4 GHz antennas. You can connect any 2.4 GHz antenna to input connector. This low noise amplifier will give you an extra 18 dB gain in 2.4 GHz band.  The output connector is a male SMA type. Battery 9 V will last 14-20 hours. TEST RESULTS MORE INFO

Order AMP-18M model price: $149.00 US

Top

HIGH GAIN AMPLIFIER FOR 900 MHz RECEIVERS

Model: AMP-23M /900

This is an excellent small amplifier for any 900 MHz receiver. This low noise amplifier will give you an extra 23 dB! gain in 900 MHz band. Also it has a Band pass filter for 900 MHz band to cut all undesired frequencies!  It will increase a gain of your receiver without adding large Yagi antennas. You can connect any 900 MHz antenna to this amplifier. The output connector is a BNC type. Battery 9 V will last 14-20 hours. MORE INFO

TECHNICAL SPECIFICATIONS:

Order AMP-23M/900 model price: $169.00 US
Top

HIGH GAIN AMPLIFIER FOR 900 MHz RECEIVERS

Model: AMP-900 /23M

This is an excellent amplifier for any 900 MHz receiver. This low noise amplifier will give you an extra 23 dB! gain in 900 MHz band. Also it has a Band pass filter for 900 MHz band to cut all undesired frequencies!  It will increase a gain of your receiver without adding large Yagi antennas. You can connect any 900 MHz antenna to this amplifier. The output connector is a BNC type. The power supply is included. MORE INFO

TECHNICAL SPECIFICATIONS:

Order AMP-900/23M model price: $249.00 US
Top

HIGH GAIN AMPLIFIER FOR TV UHF RECEIVERS

Model: AMP-4786

This is an excellent small amplifier for any TV UHF receiver (not for transmitters). It will increase a gain of TV UHF set, VCR or receiver in 470 MHz- 860 MHz range with over 23 dB. The output cable is open. Input connector is F TV type. Battery 9 V will last 14-20 hours. TEST RESULTS MORE INFO

TECHNICAL SPECIFICATIONS:

BATTERY POWER 7.5V- 12V CURRENT CONSUMPTION 30 mA RF IN/OUT 75 ohms (TV) FREQ. RANGE: 470-860 MHz INPUT CONNECTOR TV F TYPE

HIGH GAIN 23dB / 860 MHz SIZE: 1.0" x 0.7" X 0.2" WEATHERPROOF BUILT-IN BAND PASS TV  UHF FILTER LOW NOISE FIGURE <2 dB

Order:

Order AMP-4786 model price: $149.00 US

Top

HIGH GAIN AMPLIFIER FOR 5.8 GHz RECEIVERS

Model: AMP-58/18

This is an excellent small amplifier for any receiver (not for transmitters). It will increase a gain of any 5.8 GHz receiver without adding larger 5.8 GHz antennas. This low noise amplifier will give you an extra 15 dB gain in 5.8 GHz band. The output connector is a male SMA type. Battery 9 V will last 14-20 hours. MORE INFO

TECHNICAL SPECIFICATIONS:

BATTERY POWER 9V- 12V CURRENT CONSUMPTION 55 mA RF IN/OUT 75 ohms FREQ. RANGE: 5600-5900 MHz

HIGH GAIN 15dB / 5800 MHz SIZE: 1.0" x 0.7" X 0.2" INTERNAL RF FILTER LOW NOISE FIGURE <0.5 dB

Order:

Order AMP-58/18 model price: $199.00 US
